Clamp Meter / PM2118 / 600V / 600A / 60MΩ / 6mF / 1kHz / 1000°C / NCV / LowZ
Producer:
PeakMeter
Model:
PM2118
Product number:
009-17116
Warranty:
12 months
Delivery period:
Next Day Delivery
Ksh. 6700.00
Add to cart
Buy
Order by phone: +254 707 431 038
SEDN A REQUEST
Description
Characteristics
Documents
Clamp Meter / PM2118 / 600V / 600A / 60MΩ / 6mF / 1kHz / 1000°C / NCV / LowZ
PM2118 is a multifunctional clamp meter model that measures AC/DC current and voltage, frequency, resistance, temperature and capacitance.
The screen is a two line design which allows two values to be measured and displayed at the same time, for example voltage and current.
It has a backlit LCD display which allows it to be used even in poorly lit areas.
It has automatic range selection which makes use of the device very convenient.
The clamps open up to 24 mm wide.
It also features non-contact detection of live wires (NCV), diode test and circuit test with sound.
It has a reading hold which prevents the loss of data while in use.
It also has a low battery indicator and automatic power-off function after a period of inactivity to save battery power.
The key feature of this devices the LowZ mode. This measures voltage with reduced input resistance which eliminates the influence of possible interference.
PM2118 is a multifunctional clamp meter model that measures AC/DC current and voltage, frequency, resistance, temperature and capacitance.
The screen is a two line design which allows two values to be measured and displayed at the same time, for example voltage and current.
It has a backlit LCD display which allows it to be used even in poorly lit areas.
It has automatic range selection which makes use of the device very convenient.
The clamps open up to 24 mm wide.
It also features non-contact detection of live wires (NCV), diode test and circuit test with sound.
It has a reading hold which prevents the loss of data while in use.
It also has a low battery indicator and automatic power-off function after a period of inactivity to save battery power.
The key feature of this devices the LowZ mode. This measures voltage with reduced input resistance which eliminates the influence of possible interference.
| Mode | Scope | Accuracy |
| DC Voltage | 6V / 60V / 600V | (0.5%+3 units) |
| AC Voltage | 6V / 60V / 600V | (0.8%+5 units) |
| DC Current | 6A / 60A / 600A | (3.0%+3 units) |
| AC Current (up to 1000 Hz) | 6A / 60A / 600A | (2.5%+5 units) |
| Resistance | 6kΩ/60kΩ/600kΩ/6MΩ/60MΩ | (0.8%+3 units) |
| Capacity | 600uF/6mF | (4.0%+3 units) |
| Frequency | 40Hz - 1kHz | (1.0%+5 units) |
| Temperature | from -20°C to 1000°C | (1.0%+5 units) |
| Display | 6000 reading options | |
| Diode test | √ | |
| Circuit tester with sound | √ < 30Ω | |
| Low battery indicator | √ | |
| Automatic shutdown | √ | |
| Backlight | √ | |
| Pliers opening | 24 mm | |
| Mass | 150g | |
| Dimensions | 158X53X28mm | |
| Power supply | 2 x 1.5V AAA | |
| Safety standards | EN61010-1,-2-030, EN61010-2-032, EN61326-1,CAT.III 600V |
