Electrical Level Switches

Electric tank float / Plastic / Normally closed contact / MR-L5

Producer:
Saier Sensor
Model:
MR-L5-PP-2A
Product number:
469-19115
Warranty:
6 months
Delivery period:
Next Day Delivery
Ksh. 1280.00
Add to cart
Buy Now
Order by phone: +254 707 431 038
SEDN A REQUEST
Send
Description
Characteristics
Documents

Electric tank float / Plastic / Normally closed contact / MR-L5

The float can operate in a temperature range of -10 to 85°C, making it suitable for a variety of conditions. The thread diameter of the screw for mounting the float is 17 mm in diameter. Gaskets and a clamping nut are included in the kit, which can be used for a secure and airtight installation.

This type of float is often used in various applications where it is necessary to control the level of liquid in tanks or vessels with the corresponding characteristics for operation at certain temperatures.

The float is made of plastic. Mounts on the side of the tank. The float contact is normally closed. This means that when the liquid level in the tank reaches the float and lifts it up, the contacts close. When the float is down, the contacts break.

Maximum Contact Power: 50W
Maximum Switch Voltage: 350VDC/300VAC
The device can operate at voltages up to 350V DC and 300V AC.
Minimum breakdown voltage: 600VDC
With this high technical indicator, the device is protected against possible electrical disturbances and breakdowns.
Maximum switching current: DC0.7A/AC0.5A
The switch can handle up to 0.7 amps of DC current and 0.5 amps of AC current, ensuring stability at high currents.
Maximum carrying current: 2.5A
The device can reliably carry current up to 2.5 amps, ensuring optimal efficiency when working with high currents.
Minimum insulation resistance: 100mΩ
Maximum contact resistance: 1010Ω
With low contact resistance, this switch provides excellent conductivity and reduces power loss.
Operating range: -10°C to + 80°C
Allows the device to function stably and reliably in both extreme cold and hot conditions.
Material: PP (Polypropylene)
Floating ball pressure resistance: 0.7Mpa
The device can withstand a pressure of 0.7 megapascals, protecting it from damage.


Maximum contact power50W
Maximum switch voltage350VDC/300VAC
Minimum breakdown voltage600VDC
Maximum switching currentDC0.7A/AC0.5A
Maximum carrying current2.5A
Minimum insulation resistance100mΩ
Maximum contact resistance1010Ω
Temperature range-10~+85℃
MaterialPP
CarvingM16*2.8
Resistance to floating ball pressure0.7Mpa
CableUL 1015 22AWG / 300mm / PVC
Standard float ballØ17*51.5
